500W DC UPS – Guaranteed power during unexpected AC cuts

AC/DC Battery chargers, AC/DC UPS

EDS-500

The EDS-500 is a 500W battery charger that allows feeding DC loads through the charger´s batteries even if there is an AC mains cutdown. This UPS (uninterruptible power supply) series is perfect for charging lead-acid batteries of 12V, 24V and 48V and includes internal battery cut off when battery is low. Other battery types available under request.

The EDS-500 works with universal input (110-230Vac) and is available with different output combinations. This UPS series has been designed to work in applications such as 4.0 industry, Internet of Things and smart grids, and is presented in a very compact design whilst offering a reliable and efficient solution to minimize the loss of power in a robust case.

Looking for an EDS-500 with different technical features? Tell us your challenge and we’ll make it ours from now on!

Product warranty

3 years

SKU: EDS-500 Categories: AC/DC Battery chargers, AC/DC UPS Tags: 500w, ac/dc battery chargers, ac/dc UPS

EDS-500	INPUT VOLTAGE RANGE	NOMINAL OUTPUT VOLTAGE	MAXIMUM OUTPUT POWER	MAXIMUM OUTPUT CURRENT	MAXIMUM OUTPUT PEAK CURRENT FROM BATTERY
EDS-500-5243	90 … 264Vac	12V	500W	36.7A	50A 30s
EDS-500-5247	90 … 264Vac	24V	500W	18.4A	30A 30s
EDS-500-5249*	90 … 264Vac	48V	500W	9.19A	15A 30s
EDS-500-5251*	90 … 264Vac	110V	500W	4A	6.5A 30s

Quick vision

– 3 state battery charging
– Smart battery test by capacity measurement discharging over the load
– Internal battery cut off when battery is low
– Voltage/temperature compensation included
– Cooling through natural convection
– 3000 Vac input/output isolation
– Selectable maximum current charging levels
– Advanced configuration via RS232
– Optional CAN BUS or Ethernet port
– Battery temperature sensor input
– Battery voltage sense input
– Battery low alarm
– Up to 93% efficiency
– IEC62368-1 Compliant

More information

At Premium PSU we offer to possibility to modify the EDS-500 smart battery charger to each project´s needs to make it the best solutions for each application. Flexibility and customization is our standard, so don’t hesitate to contact us and tell us about your project.
